T410 – Self Aligning Rotational and Levelling Laser The T410 is the first high precision, self calibrating and self aligning laser source in the world. The laser can be completely controlled by a PC. This device is the second generation of digital laser from Status Pro. Even a self aligning with the sensors is possible just by a click in the software. The complete equipment is connected by Bluetooth so that the handling is as easy as possible.

SP Toolkit 3 This package contains all items of Toolkit 1 and Toolkit 2.Precise and effective Measurements require an appropriate mechanical adaptation. You need to have the right kit in the right place at the right time. This is adapter package is a must for professional alignment people. Naturally all the individual elements are separately available. Content: Quantity Part No. Item 1 BG 832253 T430 Adapter for large L bracket Interface to BG 832254 1 BG 832252 Switch Magnet Base for T430 Interface Plate BG_832251 1 BG 832251 T430 Toolkit Interface Plate 1 BG 832254 90° Adapter for T430 mounting 1 BT 989119 Allen key, 3 mm 1 BT 989083 Allen key, 4 mm 1 BG 832255/1 Universal G-Klamp for T430 3 BG 832256 Mini Tripod Magnetic foot 3 BG 832257 Short Tripod Leg 1 BG 832258 Tripod head for T430 1 BG 832259 T430 Tripod Interface for Tripod head BG 832258 1 BG 832260 Tripod Gimbal head for T430 1 BG 832261 Short tripod extension 1 BG 832262/1 Tripod Leg extension in Carbon, length: 42,5 up to 129 cm 3 BG 832263 Mini Tripod Legs 200mm

SP Toolkit 2 Precise and effective Measurements require an appropriate mechanical adaptation. You need to have the right kit in the right place at the right time. Content: 1 BG 832255/1 Universal G-Klamp for T430 3 BG 832256 Mini Tripod Magnetic foot 3 BG 832257 Short Tripod Leg 1 BG 832258 Tripod head for T430 1 BG 832259 T430 Tripod Interface for Tripod head BG 832258 1 BG 832260 Tripod Gimbal head for T430 1 BG 832261 Short tripod extension 1 BG 832262/1 Tripod Leg extension in Carbon, length: 42,5 up to 129 cm 3 BG 832263 Mini Tripod Legs 200mm

SP Toolkit 1 Precise and effective Measurements require an appropriate mechanical adaptation. You need to have the right kit in the right place at the right time. Content: Quantity Part No. Item 1 BG 832253 T430 Adapter for large L bracket Interface to BG 832254 1 BG 832252 Switch Magnet Base for T430 Interface Plate BG_832251 1 BG 832251 T430 Toolkit Interface Plate 1 BG 832254 90° Adapter for T430 mounting 1 BT 989119 Allen key, 3 mm 1 BT 989083 Allen key, 4 mm

ProLevel® v2 Software for professional Flatness and Level measurementsEasy measurement and professional analysis: Automatically connection management, wireless via Bluetooth  Measurement of unlimited points  Free positioning of point coordinates  Zeroing of three points or best-fit analysisAdjustment with live values 3D viewData view with all values and calculationsOne click export of all graphics and data in table formatEasy to use touchscreen software

T430 Sweep Laser The T430 is a precision Laser self-levelling Laser Transmitter. It has several unique features which make it ideal for the alignment of machine tools. For example: In spite of its performance spec the unit is very small 96 x 96 mm x 121 mm. It has fiberoptical laser source which is exactly round and of Gaussian intensity distribution. It has a self calibrarion function because the house is able to rotate 360. The T430 generates two orthogonal optically coupled Laser beams. These and many other make the T430 ideal for machine tool alignment.

R290 Laser ReceiverThe R290 measures the position of the rotating laser beam. The CCD Sensor has total measurement range of 40 mm. The beam forms an entire reference plane. The R290 is wireless and can measure up to a distance of 80m from the Laser.

Carbon TripodBig Carbon Tripod with extensions. Length: 180 – 2500 mm.For mounting a T430 laser an 3/8 inch adapter is required. Request.

 R260 Laser ReceiverThe R260 measures the position of the rotating laser beam. The CCD Sensor offers a total measurement range of 60mm.The laser-beam forms an reference plane. This reference plane can be measured by the R260.The Receiver offers a display on top in combination with a attachable mirror. So you can view the values from the front, the top and from behind! Additional there is a LED display on the front which indicates the current position of the laserbeam.By using the keypad at the side you can control the receiver and the laser. By using the bluetooth connection values can be automatically send to our software by pressing a "measurement" button.
